Name: Electric Start 5kVA Portablel Diesel Small Portable Generators AC Single Phase Generators
Brand: GPRO
Price: 1 USD

Add to Cart

Electric start 5kVA portablel diesel generator AC single phase generators

Genset	Model No.	6500E (Open type)	PD6500T (Silent type)
	Rated frequency (Hz)	50/60	50/60
	Rated voltage (v)	230 120/240	230 120/240
	Rated output power(kW)	5.0 6.0	5.0 6.0
	Rated rotation speed(rpm)	3000/3600	3000/3600
	DC Output	12v 8.3A	12v 8.3A
	Power factor	1	1
	Phase number	Single phase	Single phase
	Noise level dB@7m	85	75
	Overall dimension (LWH)MM	780x500x650	950x560x750
	Net weight	107	165

Engine	Engine type	186FAE	188FAE
	Structure type	Single cylinder , in lined 4 stroke, air cooled direct injection	Single cylinder , in lined 4 stroke, air cooled direct injection
	Bore * stroke mm	86X72	86X72
	Displacement ml	418	418
	Compression ratio	19:01	19:01
	Rated output(kw/rpm)	5.9/3000 6.5/3600	5.9/3000 6.5/3600
	Lubrication system	pressure splashed	pressure splashed
	Lue oil brand	Above CD SAE 10W 30 15W 40	Above CD SAE 10W 30 15W 40
	Staring system	Recoil starter	12V Electric starter
	Starting motor capacity	12V 0.8KW	12V 0.8KW
	Charging generator capacity	12V 3A	12V 3A
	Battery capacity	12V 36AH	12V 36AH
	Fuel consumption rate(g/kw.h)	3000rpm 276,3600rpm 285	3000rpm 276,3600rpm 285
	Fuel type	Diesel 0# or 10# 35#	Diesel 0# or 10# 35#
	Fuel tank capacity (L)	15	15
	Continuous Running time(H)	8	8

Loading quanity for 20ft container is 72 units.

Advantages:

. A strong R&D team with rigorous selection and trainning

. Several years experiences in desinging and manufacturing diesel generator sets.

. Good reputation for reliable quality and reasonable price

. Advanced production line with skilled workers

Sales Promises:

. Our company provides a full line of brand new and high quality products which are strictly tested before shipment

. Quality warranty is according to our standard conditions: One year or 1000 running hours

. During the guarantee period, the spare-parts will be sent through your shipping agency in China.
. Spare-parts can also be sent by air express.

If have any questions, please contact us. Your inquiry would be appreciated.
